JBL IRX ONE All-in-One Column PA with Built-In Mixer and Bluetooth Streaming

JBL offer peace of mind with an unrivalled 7-year warranty on select professional portable PA loudspeakers. Click here for more information.

The JBL IRX One All-in-One Column PA features an advanced acoustic package, 3-channel mixer and Bluetooth 5.0 audio streaming – all packed into an incredibly easy-to-use system that can be carried with one hand.

Utilizing concert line array-inspired directivity control, this results in a custom-tuned, C-shaped array. Featuring six 2” high-frequency drivers, the array delivers rich clarity, a wide sweet spot and seamless front-to-back coverage. The advanced 8” woofer features a bass-reflex design that ensures low-frequency response down to 40 Hz.

Designed to support a range of different users, IRX ONE features a 3-channel mixer that supports the most popular connections, including 1/4” and XLR inputs with included 48V phantom power and ¼” balanced mix-out. Dbx automatic feedback suppression (AFS), 5 EQ presets, Soundcraft audio ducking, and Bluetooth 5.0 audio streaming ensure a professional experience from start to finish.

Key Features:

• Making life easy:
  With fixed bass and treble control, Automatic Feedback Suppression (AFS), phantom power, and system tuning presets, you will be rocking in no time.
• Automatic calibration:
  Speaker automatically adjusts tuning depending on how many spacers are used for optimum sound performance.
• Practical:
  Easy to carry with one hand; sets up and tears down in seconds

Specifications:

• Driver Sizes:
  – Woofer: 8 Inch
  – Tweeter: 2 Inch
• MAX SPL: 118dB(peak)
• Frequency Ranges:
  – -10: 40Hz ~ 20KHz @ 4pi
  – -3: 50Hz ~ 18KHz @ 4pi
• Hor Dispersion: 160 degrees
• Vert Dispersion: 80 degrees
• Power:
  – Rating: 1300W Peak
  – AC Input: 100V – 120V or 220 – 240V
• Input Impedance:
  – 4.4k ohms Input Mic
  – 1Mohms balanced Hi-Z Jack
• Input Mic Gain: 55dB
• Input Gain Hi Z: 48dB
• Crossover Frequency: 260Hz
  – I/O:
  —- 2 – Mic/line XLR Combo
  —- 1 – HiZ In – 6.3mm jack
  —- 1 – Mix Out – 6.3mm jack
  —- 1 – Bluetooth SBC
• Cabinet: PP
• Dimensions: (L x W x H):
  – Length: 267mm / 10.5”
  – Width: 400mm / 15.73”
  – Height: 597mm / 23.5”
  – Weight: 18.39kg / 40.5 lbs
