Soundcraft SCR,Mini Stagebox 32i EU

The Soundcraft Mini Stagebox 32i gives you an easy stage-connectivity solution. This 3U chassis gives you 32 analogue mic/line inputs, 12 analog line outputs, and dual MADI connections, for a total I/O capacity of 32 inputs and 12 outputs. These Mini Stage-box units interface with Soundcraft Si Series consoles via remote control, giving you wireless mixing power. They sport an integral PSU, making them completely self-contained for convenient stage-side placement. Expand your wireless mixing capabilities with the Soundcraft Mini Stagebox 32i.

No more heavy and expensive snakes:

One of the main benefits of outfitting your Soundcraft Si setups with a Mini Stagebox 32i is its ability to do away with the need for inconvenient snakes. The 32i crams a total of 32 inputs and 12 outputs into a unit that connects via a single Cat 5 cable. And it does it with no need for any other local hardware configuration or option cards.

Wireless control:

If you want to gain full, wireless control of your Si Series console, you need to add the Soundcraft Mini Stagebox 32i to your rig. Need even more I/O than the 32i offers? Install a second MADI option card to your console and add a second Stagebox. From dialing in monitors right from the stage to being able to get a feel for the whole room, the 32i is the unit that will get you there.

Soundcraft Mini Stagebox 32i Features:

• Integrates with your Si Series console for wireless control
• 32 remote-controlled mic preamps
• 12 XLR line outs
• Studer-designed preamps
• Compatible with Soundcraft Si Series consoles
• Simple to use RJ45/Cat 5 connectivity

Tech Specs:

• Type:Digital Stage Box
• Compatibility: Soundcraft Si consoles
• Channels: 32 x 12
• Inputs – Mic Preamps: 32 x XLR (mic/line)
• Phantom Power: Yes
• Outputs – Main: 12 x XLR (line)
• Data I/O: 2 x RJ45 (MADI)
• Features: Remote control preamps via Si consoles
• Rackmountable: Yes
• Height: 13.34cm
• Width: 482.6cm (Standard 19″ Rack-Mount)
