Soundcraft Si Impact Professional Audio Mixer

The Soundcraft Si Impact is a 40-input digital mixing console that combines the simplicity of analog operation with the power and flexibility of digital technology. Designed for live sound environments, it features 32 microphone inputs, 8 XLR/1/4″ combo jacks for line inputs and instruments, and 26 motorized faders, including 24 input faders and LR/Mono. The console offers 40 DSP input channels (32 mono inputs and 4 stereo channels/returns) and 31 output buses, all with full DSP processing and graphic equalization. Each channel and bus is equipped with a 4-band fully parametric equalizer. The Si Impact also includes 8 VCAs, 8 mute groups, and a 5″ touchscreen display for easy access to show setup, patching, effects, and security. It supports up to four studio-grade Lexicon effects engines and dedicated FX buses, BSS graphic equalizers on every bus, and a 32×32 USB audio interface for multi-track recording and playback. The console’s FaderGlow™ system provides at-a-glance status information on precisely what each fader is controlling. Additionally, the Si Impact offers built-in stagebox connectivity and supports remote mixing via an iPad® app.

Si Impact. Innovative digital mixing with uncompromised audio quality

Drawing on over 40 years experience in live sound mixing, Si Impact brings the latest digital mix innovations together with the unrivalled sound quality of Soundcraft. Designed to be as simple as an analog mixer, but offer radical workflow enhancements such as the unique FaderGlow^™ system, massive DSP power, and a pristine 32-in/32-out USB audio interface, Si Impact delivers digital live sound mixing and recording for those who refuse to compromise on audio quality.

Key Features:

• Up to 80 channels to mix
• 32 Mic Inputs
• 8 XLR/1/4″ Combi-jacks for line inputs and instruments
• 40 DSP input channels (32 mono inputs and 4 stereo channels/returns)
• 31 Output busses (All with full DSP processing and GEQ)
• 4-band Fully Parametric EQ on each channel and bus
• 8 VCAs + 8 Mute groups
• 26 motorised faders (24 input + LR/Mono)
• 4 fully customisable Fader Layers
• Built-in Stagebox Connectivity
• 5″ touchscreen display
• Multi-Colour LCD Channel Displays on each input fader
• 4 studio-grade Lexicon Effects engines and dedicated FX busses
• BSS Graphic Equalisers on every bus
• 20 sub-group / aux busses
• 4 mono/stereo matrix busses
• 32×32 USB audio interface for multi-track recording and playback *
• Increase I/O capabilities with option cards and stageboxes:
  • Use included MADI option card and Soundcraft Mini Stagebox 32i or 16i for more microphone preamps, inputs and channels to mix
  • Add 2^nd MADI option card and two Soundcraft Mini Stagebox 32i or 16i for up to 96 microphone preamps, 136 total inputs and 80 channels to mix.
  • Add Dante option card for 64 channels of Dante to mix
  • Additional option cards available: AVIOM A-Net, CobraNet, AES/EBU, BLU Link, more
• Additional Soundcraft stageboxes available: Mini Stagebox 32R, Mini Stagebox 16R, Compact Stagebox, and Vi Stagebox
