Soundcraft Ui24R – Digital Mixing & Multi-track Recording System

The Soundcraft Ui24R is a powerful, rack mountable digital mixing and multi track recording system, designed to offer superior sound quality, flexible connectivity, and intuitive wireless control. Ideal for artists, venues, and engineers, this compact mixer provides professional performance without taking up valuable space.

With 24 input channels, including 20 Studer designed microphone preamps, the Ui24R delivers pristine audio quality and expanded creative possibilities. The system allows full wireless control from up to 10 devices via built in dual band WiFi, eliminating the need for an external router. Renowned Lexicon, dbx, and DigiTech processing ensures premium effects and dynamics, while dual path multi track recording provides simultaneous capture to USB storage and a connected computer.

Designed for both stage and studio, the Ui24R is compatible with the Harman Connected PA system, offering seamless integration for efficient setup and control. Whether used as a standalone mixer or a stagebox, this versatile unit brings the functionality of a large format console into a streamlined, space saving design.

Key Features:

• Wireless Multi Device Control:
  Control the mixer from up to 10 devices simultaneously via iOS, Android, Windows, Mac OS, and Linux browsers, with no need for additional apps.
• Comprehensive Connectivity:
  24 inputs, including 10 combo TRS/XLR, 10 XLR, 2 line level, and 2 digital USB playback channels, ensure versatility for any performance or recording setup.
• Studio Grade Sound Processing:
  Built in Lexicon reverb and delay, dbx compression, DigiTech guitar amp modelling, and advanced EQ tools provide professional grade mixing and audio enhancement.

  Specifications:

  • 24 input channels: 10 combo TRS/XLR, 10 XLR, 2 line level, 2 digital USB playback
  • 20 Studer-designed microphone preamps for premium sound quality
  • Built-in dual-band WiFi for wireless control via up to 10 devices
  • dbx compression, Lexicon reverb/delay, and DigiTech amp modelling
  • 31-band graphic EQ, noise gate, compressor, and dbx AFS2 feedback suppression
  • Multi-track recording: 24-channel USB interface for Mac/PC and direct USB storage recording
  • 4-band parametric EQ, high-pass filter, compressor, de-esser, and noise gate on inputs
  • Real-time frequency analyser (RTA) for inputs and outputs
  • Compatible with Harman Connected PA system for enhanced integration
  • 4U rackmount design for professional installation
