Full Description
Smooth dispersion for every audience member
A 90 degree x 50 degree horn provides smooth, even coverage whether used in the vertical (mains) or horizontal (monitor) orientation. For use on a tripod or over a subwoofer, JBL’s dual angle pole mount is included. This allows the PRX412M to be mounted in a vertical position or with a 10-degree down tilt for optimum audience coverage.
Rugged, road ready construction
The enclosure is constructed of birch/poplar multi-laminate hardwood and coated in JBL’s rugged DuraFlex finish. The distinctive 16-gauge steel grille is CNC-machined for precision. The grilles are internally lined with an acoustically transparent screen to provide additional driver protection and give a very professional appearance.
Features
- 90 degree x 50 degree coverage for even and smooth response on and off axis
- Dual-angle pole socket for applications requiring tripod mounting
- Heavy Duty 16 gauge protective screen backed steel grille
- Tough DuraFlex enclosure finish
- Utilizes twelve M10 suspension points for safe deployment in light duty installations
- SonicGuard protects the highfrequency driver from excess power without interrupting the performance
Specifications
- Frequency Range (-10 dB): 50 Hz – 20 kHz
- Frequency Response: 62 Hz – 19 kHz
- Coverage Pattern: 90 degree x 50 degree nominal
- System Sensitivity: 95 dB SPL (1w@1m)
- Power Rating, Pink Noise: 300 W / 600 W / 1200 W (Continuous/Program/Peak)
- Rated Maximum SPL: 126 dB SPL peak
- Nominal Impedance: 8 ohms
- Dimensions (H x W x D): 574 mm x 353 mm x 399 mm (22.6 in x 13.9 in x 15.7 in)
- Net Weight: 16 kg (35 lbs.)
